| Imaging Device |
3 x 1/3" Exmor CMOS |
| Signal to Noise Ratio |
54 dB |
| Zoom Ratio |
20x |
| 35mm Equivalent Focal Length |
29.5 - 590mm |
| ND Filters |
OFF, 1/4, 1/16, 1/64 |
| Gain Selection |
-3, 0, 3, 6, 9, 12, 18 dB |
| Sensitivity |
F9 (typical) at 2000 lx, 89.9% reflectance |
| Slow Shutter |
2, 3, 4, 5, 6, 7, 8, 16, 32, and 64-frame accumulation |
| File Format |
UDF, FAT |
| Video Recording Format |
UDF Mode (HD Recording)
MPEG HD422 (MPEG-2 422P@HL):
CBR, 50 Mb/s
MPEG HD420 (1440x1080, MPEG-2 MP@HL):
HQ mode (VBR, maximum bit rate: 35 Mb/s)
SP mode (CBR, 25 Mb/s) - playback only
LP mode (VBR, maximum bit rate: 18 Mb/s) - playback only
UDF Mode (SD Recording)DVCAM (CBR, 25 Mb/s)
FAT Mode (HD Recording)
MPEG HD420 (1920x1080, MPEG-2 MP@HL):
HQ mode (VBR, maximum bit rate: 35 Mb/s)
SP mode (CBR, 25 Mb/s)
Fat Mode (SD Recording)
DVCAM (CBR, 25 Mb/s) |
| Frame Rates |
XDCAM HD422 at 50Mbps:
1080/59.94i, 1080/29.29p, 1080/23.98p, 1080/50p, 1080/25p
720/59.94p, 720/29.97p, 720/23.98p, 720/50p, 720/25p |
| Audio Recording |
UDF Mode (HD Recording)
MPEG HD422 (MPEG-2 422P@HL):
4 channels, 48KHz, 24-bit LPCM
MPEG HD420 (1440x1080, MPEG-2 MP@HL):
4 channels, 48KHz, 16-bit LPCM
UDF Mode (SD Recording)DVCAM: 4 ch/16 bits/48 kHz
FAT Mode (HD Recording)
MPEG HD420 (1920x1080, MPEG-2 MP@HL):
2 channels, 48KHz, 16-bit LPCM
FAT Mode (SD Recording)
DVCAM: 2 channels, 48 KHz, 16-bit LPCM |
| Recording/Playback Time |
UDF Mode (HD Recording)
50 Mb/s MPEG HD422 (MPEG-2 422P@HL):
Approx. 120 min with SBS-64G1A (64 GB) memory card
Approx. 60 min with SBP-32 / SBS-32G1A (32 GB) memory card
Approx. 30 min with SBP-16 (16 GB) memory card
35 Mb/s VBR, HQ Mode MPEG HD420 (1440x1080, MPEG-2 MP@HL):
Approx. 180 min with SBS-64G1A (64 GB) memory card
Approx. 90 min with SBP-32 / SBS-32G1A (32 GB) memory card
Approx. 45 min with SBP-16 (16 GB) memory card
UDF Mode (SD Recording)
25 Mb/s DVCAM
Approx. 220 min with SBS-64G1A (64 GB) memory card
Approx. 110 min with SBP-32 / SBS-32G1A (32 GB) memory card
Approx. 55 min with SBP-16 (16 GB) memory card
FAT Mode (HD Recording)
35 Mb/s VBR, HQ Mode - MPEG HD420 (MPEG-2 MP@HL):
Approx. 200 min with SBS-64G1A (64 GB) memory card
Approx. 100 min with SBP-32 / SBS-32G1A (32 GB) memory card
Approx. 50 min with SBP-16 (16 GB) memory card
25 Mb/s CBR, SP Mode - MPEG HD 420 (MPEG-2 MP@HL-14):
Approx. 280 min with SBS-64G1A (64 GB) memory card
Approx. 140 min with SBP-32 / SBS-32G1A (32 GB) memory card
Approx. 70 min with SBP-16 (16 GB) memory card
Fat Mode (SD Recording)
25 Mb/s DVCAM
Approx. 220 min with SBS-64G1A (64 GB) memory card
Approx. 110 min with SBP-32 / SBS-32G1A (32 GB) memory card
Approx. 55 min with SBP-16 (16 GB) memory card |
| Recording Media |
2 x SxS Express 34 Cards |
| Inputs |
2 x XLR-type 3-pin (female): line, mic, mic +48 V selectable
1 x BNC (switchable to Video Out), 1.0 Vp-p, 75?
1 x BNC, Timecode In (switchable to TC Out), SMPTE-12M-2008, 0.5-1.8 Vp-p, 10k?) |
| Outputs |
1 x A/V out jack: 10 pin connector
1 x BNC, (switchable to Genlock In), HD-Y / Composite switchable, 1.0 Vp-p, 75?
1 x BNC, HD/SD switchable, SMPTE-292M/259M
1 x BNC, Timecode Out (switchable to TC In), SMPTE-12M-2008, 1.0 Vp-p, 10k? |
| USB 2.0 |
1 x mini-B |
| IEEE-1394 |
1 x 4-pin, HDV (HDV 1080i) / DV input/output, S400 |
| Earphone |
1 x Mini-jack (stereo) |
| Built-in Speaker |
Monaural, 250 mW |
| Viewfinder |
Electric Viewfinder (EVF)
Approx 1.2 million pixels
852 x 3 x 480 (HxRGBxV) |
| LCD Monitor |
3.5" (8.9 cm) color LCD
852 x 3 x 480 (HxRGBxV)
Aspect Ratio: 16:9 |
| Built-In Microphone |
Omni-directional stereo electret condenser |
| Wi-Fi |
Yes |
| Humidity |
10 to 90% (relative humidity) |
| Storage Temperature |
-4 to 140&def;F (-20 to 60F) |
| Operating Temperature |
32 to 104F (0 to 40C) |
| Power Requirements |
12 VDC |
| Dimensions (WxHxD) |
6.77 x 6.46 x 12.83" (17.2 x 16.4 x 32.6 cm) (without protrusions) |
