Sensor

1/2.3" back-illuminated Exmor R CMOS sensor

Pixel Gross

Approx. 18,900,000 pixels

Effective Pixels

Approx. 8,300,000 pixels

Color Filter System

RGB primary color filters

Lens

Sony G Lens

Image Stabilization

Optical SteadyShot image stabilization

Aperture

f/1.6 - f/3.4

Focal Length

4.1 - 82 mm

35mm Equivalent Focal Length

31.5 - 630 mm

Optical Zoom

20x

Filter Diameter

72 mm

Minimum Focus Distance

Wide: Approx. 0.4" (1 cm)
Tele: Approx. 31.5" (80 cm)

Aperture Blade

6 blades

ND Filter

Off
1/4
1/16
1/64

Control Rings

Focus ring
Iris ring
Zoom ring

Recording

Video Signal

UHDTV
HDTV

Video Format

XAVC-S format
MPEG-4 AVC/H.264

Compatible Formats

XAVC-S: MP4 (4:2:0, 150 Mbps, 4K 3840 x 2160/60p)
XAVC-S: MP4 (4:2:0, 150 Mbps, 4K 3840 x 2160/50p)
XAVC-S: MP4 (4:2:0, 60 or 100 Mbps, 4K 3840 x 2160/30p)
XAVC-S: MP4 (4:2:0, 60 or 100 Mbps, 4K 3840 x 2160/25p)
XAVC-S: MP4 (4:2:0, 60 or 100 Mbps, 4K 3840 x 2160/24p)
XAVC-S: MP4 (4:2:0, 50 Mbps, HD 1920 x 1080)
AVCHD: m2ts (4:2:0, up to 28 Mbps, HD 1920 x 1080)

Media Type

XQD memory card x 2

Video Resolution

4K: 3840 x 2160p at 60 fps (150 Mbps)
4K: 3840 x 2160p at 30 fps (100 Mbps)
4K: 3840 x 2160p at 30 fps (60 Mbps)
4K: 3840 x 2160p at 24 fps (100 Mbps)
4K: 3840 x 2160p at 24 fps (60 Mbps)
4K: 3840 x 2160p at 50 fps (150 Mbps)
4K: 3840 x 2160p at 25 fps (100 Mbps)
4K: 3840 x 2160p at 25 fps (60 Mbps)
HD: 1920 x 1080p at 60 fps (50 Mbps)
HD: 1920 x 1080p at 30 fps (50 Mbps)
HD: 1920 x 1080p at 24 fps (50 Mbps)
HD: 1920 x 1080p at 50 fps (50 Mbps)
HD: 1920 x 1080p at 25 fps (50 Mbps)

Recording Time

50 min with 64GB XQD card (XAVC-S 3840 x 2160/60p, 150 Mbps)
150 min with 64GB XQD card (XAVC-S 1920 x 1080p/60p, 50 Mbps)

Video Actual (Pixels)

Approx. 8,300,000 pixels

Audio Format

Linear PCM (48 kHz / 16-bit)

Audio Channels

2-channels

Microphone Max Input Level

120 dB SPL

Built-In Microphone

Yes (2-channel stereo microphone)

Built-In Speakers

Yes (monaural speaker)

Microphone Level Control

Yes (2 steps)

Wind Position

Yes (On/Off)

Viewfinder

Type

0.45" (1.14 cm)

Backlight

Yes

Power Mode

Yes

Display

LCD Type

3.5" (8.8 cm) Xtra Fine LCD 3D display

Pixels

1,229,000 pixels

Aspect Ratio

16:9 (wide)

Angle Adjustment

Opening Angle: 180 (max)
Turning Angle: 270 (max)

Backlight

Yes (menu)

Coverage

100%

Marker

Yes

Focus Control

Focus System

Contrast AF

AF Modes

Auto
Manual (ring)

Focus Area

Full range focus

Push Auto Focus

Yes

Manual Focus Assist

Magnified display for precise manual focus
Peaking display

Exposure Control

Metering Modes

Multi-segment

Exposure Compensation

AE level
AE speed (menu)

Noise Reduction

Yes

White Balance Modes

Auto
One Push
Outdoor
Indoor
Color Temp

WB Shift

Yes

Minimum Illumination

60p: 4 lux (1/30 shutter speed)
50p: 3 lux (1/25 shutter speed)

Auto Iris Control

f/1.6 - f/11

Manual Iris Control

f/1.6 - f/11

Push Auto Iris

Yes

Manual Exposure Assist

Zebra pattern display

Connectivity

Memory Card Slot

XQD x 2 (for XAVC-S)
Memory Stick PRO Duo
Memory Stick PRO-HG Duo
SD/SDHC/SDXC compatible x 1 (for AVCHD)
SD/SDHC/SDXC x 1 (utility SD slot)

A/V Outputs

Composite video (RCA) output x 1 (SD)
Analog audio L/R (RCA) output x 1 (SD)
HDMI output x 1 (HD/4K)

USB Ports

USB 2.0 Hi-Speed (mini-B) x 1
USB 2.0 Hi-Speed Host (mass-storage type-A) x 1

Headphone Jack

Stereo mini-jack x 1

Microphone Input

XLR jacks x 2 (line/mic)

DC Input

Yes

Remote Terminal

Yes

Accessory Shoe

Yes

General

Battery Type

NP-F970

Power Requirements

7.2 V (battery pack)
12.4 V (AC adapter)

Power Consumption

Viewfinder (4K): 14.2 W (30p / 60 Mbps)
Viewfinder (HD): 15.4 W (60p / 50 Mbps)
LCD (4K): 14.5 W (30p / 60 Mbps)
LCD (HD): 15.7 W (60p / 50 Mbps)

Dimensions (WxHxD)

7.44 x 7.6 x 14.25" (189 x 193 x 362 mm) including NP-F970 battery

Weight

5.38 lb (2.44 kg) camera only
6.1 lb (2.77 kg) camera and NP-F970 battery
