Supply Voltage
DC7.2V / 7.9V
Power Consumption
11.6W (when viewfinder is used), 12.0W (when LCD monitor is used) MAX 14W
Operating Temperature
0°C to +40°C
Operating Humidity
10% to 85% (no condensation)
Pick-up Device
3CCD (1/3-inch interline transfer type and progressive modes supported)
Lens
LEICA DICOMAR lens with optical image stabilizer, motorized/manual mode switching,13 x zoom, F1.6 to F 2.8 (f= 4.2mm to 55mm) (35mm equivalent: 30.3mm to 394mm)
Optical Colour Separation
Prism system
ND Filter
1/8, 1/64
Gain Selection
50i/50p mode: 0/+3/+6/+9/+12/+18 dB (when using slow shutter, 0 dB fixed) 25p/25pN mode: 0/+3/+6/+9/+12 dB (when using slow shutter or VFR rate of less than 25p: 0 dB fixed)
Frame Rate
variable 12/18/20/23/25/27/30/32/37/48/50 fps (frame/sec)
Frame Rate
variable 12/18/20/23/25/27/30/32/37/48/50 fps (frame/sec)
Shutter Speed (Preset)
50i/50p mode: 1/50 (OFF), 1/60, 1/120, 1/250, 1/500, 1/1000, 1/2000 sec.
25p/25pN mode: 1/25, 1/50 (OFF), 1/60, 1/120, 1/250, 1/500, 1/1000 sec.
Shutter Speed (Synchro Scan)
50i, 50p mode: 1/50.0 sec. to 1/248.9 sec
(Synchro Scan) 25p, 25pN mode: 1/25.0 sec. to 1/248.9 sec.
Aperture Angle
10° to 350° (Shutter Angle is selectable under Film Cam Mode.)
Slow Shutter Speed
50i/50p mode: 1/25, 1/12
25p, 25pN mode: 1/12 sec.
Minimum Luminance
3 lx (F1.6, +12 dB gain, at 1/25 shutter)
Lens Hood
Large lens hood with wide view angle
Filter Diameter
82mm
Sampling Frequency
Y: 74.25 MHz, PB/PR: 37.125 MHz
Quantizing
8 bits
Compression
Compression ratio 1/6.7, DCT + variable length code
Recording Bit Rate
100Mbps
Memory card Recording Format
DVCPRO HD
1080/50i, 1080/25p over 50i
720/50p, 720/25p over 50p, 720/25pN (Native Record)
DVCPRO 50/DVCPRO/DV
576/50i, 576/25p over 50i
Memory Card Audio Recording Format
PCM digital recording 48 kHz /16 bits
4ch (DVCPRO HD/DVCPRO 50),
2ch/4ch selectable (DVCPRO/DV)
Memory Card Recording Time
32 minutes with one AJ-P2C032RG (DVCPRO HD, 1080/50i)
64 minutes with one AJ-P2C032RG (DVCPRO HD, 720/25pN)
Recording Format
Digital Video SD
Tape Format
Mini DV cassette (6.35mm width metal evaporated tape)
Recording Video Signals
576/50i (PAL Digital Video, Standard Definition)
576/25p mode (all convert to 576/50i and record)
Recording Audio Signals
PCM digital recording, 16 bits: 48kHz/2ch or 12 bits: 32kHz/4ch
Wow & Flutter
Below measurable limits
Recording Tracks
Digital video / audio signals: helical track
Time code: helical track (sub-code area)
Tape Speed
SP mode: 18.831mm/sec, LP mode: 12.568mm/sec
Recording Time
SP mode: 63 min. (When using AY-DVM63MQ)
FF/Rew Time
Approx.140 sec. (when AY-DVM63MQ is used)
Video Out
Analogue component, Y: 1.0Vp-p , 75O, PB/PR: 0.7Vp-p , 75O
Video In/Out
Pin Jack x 1, Analogue composite, 1.0Vp-p , 75O (In/out automatically switched, Input DV tape mode only)
S-video In/Out
4-pin, Y/C Y: 1.0Vp-p , 75O, C: 0.3Vp-p , 75O (In/out automatically switched, Input DV tape mode only)
Component Analogue Out
D-Connector for HD Images
XLR In
XLR (3 pin) x 2 (Input 1/Input 2), Input: High impedance
Line: 0dBu, MIC: -50/-60 dBu (selectable in menu)
Line In/Out
Pin Jack x 2 (Input 1/Input 2), (automatically switched),
In: High impedance 316mV, Out: 600O, 316mV
Internal Microphone
Stereo Microphone
Phones
Stereo Mini jack (3.5mm diameter)
Internal Speaker
28mm round shape x 1
IEEE 1394
4-pin Digital input/output, based on IEEE 1394 standard
USB
Type mini B connector (USB ver.2.0)
Camera Remote
Zoom, Rec (Start/Stop) Super Mini jack (2.5mm diameter)
Focus Iris, Mini jack (3.5mm diameter)
DC Input
2P x 1, 7.9V
LCD Monitor
3.5 inches, LCD colour Monitor, 210,000 pixels
Viewfinder
0.44 inches, LCD colour Viewfinder, 235,000 pixels
Dimensions (WxHxD)
168.5 x 180 x 390 mm
Weight
Approx. 2.5kg excluding battery and accessories
